EN1092 ASTM A182 F304 Stainless Steel RF Plate/Flat Flange

EN1092 ASTM A182 F304 Stainless Steel RF Plate/Flat Flange

Followings are the definition, information and application of  various types of flanges:

Weld Neck Flange Slip On Flange Blind Flange Threaded Flange
Plate/Plain Flange Socket Weld Flange Orifice Flange Spectacle Blind Flange
Lap Joint/Loose Flange Long Weld Neck Flange Reducing Flange Rolled-Forging Ring Flange
Flange-Olet Tube Sheet/Tubesheet Anchor Flange Non-Standard/Custom Flange

SPECIFICATION:

The plate flange slip over the pipe and the inner hole of plate flange is a little bigger than the pipe outer diameter. plate flanges are secured to the pipe with a fillet weld at the bottom and the top of flanges with the pipes. The welding method is fillet weld, so the plate flange is not suitable for a high pressure application.

EN1092 ASTM A182 F304 Stainless Steel RF Plate/Flat Flange

Standard:   ANSI/ASME B16.5, ANSI/ASME B16.47, BS4504, BS3293, EN 1092, DIN2631,DIN2632,DIN2633, DIN 2634, DIN2635, DIN2636, DIN2637, DIN2638, JIS B2220, SABS / SANS 1123 , GOST / ГОСТ 12821-80 Flange, MSS SP-44 FLANGE, API 6A, 6B, 6BX weld neck FLANGE, ISO 7005 Weld neck flange. NFE 29203 Weld neck flange, KS B1503 , UNI 2280-67 ,UNI 2281-67 ,UNI 2282-67 ,UNI 2283-67 , UNI 2284-67, HG20595,AS2129.

Pressure: Class 75, Class125, Class 150, Class 300, Class 400, Class 600, Class 900, Class 1500,Class 2500,3000 PSI, 5000 PSI, 10000 PSI, 20000 PSI.

        PN2.5, PN6, PN10, PN16, PN25, PN40, PN64, PN100, PN160

        5K, 10K, 15K, 20K, 30K.

Material:

Carbon steel:  ASTM A105, A181, ASTM A516 GR.60, GR.70, ASTM A694 F42, F46, F52, F56, F60, F65, F70, ST37, ST45.8, C22.8, S235, S235JRG2, P235GH, P245GH, P250GH, P265GH, P355GH, S355J2, 16MN, 20MN, Q235, 20#, CT20, SS400.

Stainless steel:  ASTM A182 F304, F304L, F316, F316L, F321, F321H, F304H, F316H, F347H, 1.4301, 1.4306, 1.4401, 1.4404, 1.4541, 1.4571, SUS304, SUS316.

Alloy Steel:   ASTM A350 LF2, CL1/CL2, ASTM A182 F5, F9, F11, F12, F22, F91.

Duplex Steel:  S31803  /  F51  /  S32205  /  F60  /  1.4462

Super Duplex:  S32750  /  F53  /  1.4410  /  S32760  /  F55  /  1.4501

Sealing face: Raised Face(RF), Flat Face(FF), Ring Type Joint(RTJ).

Flange face finishing, MSS-SP-6, such as: Stock finishing, Spiral serrated finishing, concentric serrated finishing, smooth finishing etc.

Coating: Black paint, Yellow paint, Vanish oil

Packing:  Wooden case, Plywood case, Pallet.

Marking: MSS-SP-25, necessary information of flange specification, Customized marking is available.

CERTIFICETE:

BS EN10204 3.1 MTC, ABS, PED 97-23-EC, CE, ISO, API approved.

API CE ISO PED ABS Certified

API CE ISO PED ABS Certified

Hebei Haihao Flange factory can produce the plain flange (plate flange) according to customer request.
