Custom 600# RTJ Sight Glass Flange Supplied to Côte d’Ivoire
Haihao Group is proud to supply a specially manufactured 600# RTJ sight glass flange to a valued customer in Côte d’Ivoire. Designed for high-pressure pipeline systems, this flanged straight-through sight glass allows operators to visually monitor fluid flow, ensuring safety and process control in demanding industrial environments such as petrochemical, offshore, and chemical processing plants.
Made from premium 316 stainless steel (316SS), this sight glass flange offers excellent corrosion resistance, mechanical strength, and durability for harsh operating conditions.
Haihao Group manufactured 600# RTJ 316SS sight glass flange
What is a sight glass flange?
A sight glass flange is a special type of pipeline fitting that allows operators to visually inspect the flow of liquids or gases within a piping system. Installed as part of the pipeline, this device provides a clear, real-time view of the internal process without the need to open or disassemble the system, ensuring operational safety and efficiency.
Technical Specifications
| Item | Details |
|---|---|
| Product | RTJ Sight Glass Flange |
| Size | 2” |
| Pressure Class | 600# RTJ |
| Body Style | Flanged, Straight Through |
| Material | 316 Stainless Steel (316SS) |
| Face-to-Face Length | Manufacturer Standard (MFR STD) |
| Overall Length (L) | 362 mm |
| Working Pressure | 53 bar |
| Wall Thickness | STD (Standard) |
| End Connection | RTJ Flanged |
Haihao Group manufactured 2 inch 600# RTJ Sight Glass Flange in 316SS
Project Background: Custom Design for Côte d’Ivoire Client
This 2″ 600# RTJ sight glass flange was custom-designed and produced for a pipeline project in Côte d’Ivoire. The client required a solution that combined reliable visual flow monitoring with high pressure resistance. After detailed discussions regarding application environment and operational conditions, Haihao Group delivered a product fully compliant with international standards, offering superior sealing performance thanks to its RTJ (Ring Type Joint) flange design.
The choice of 316SS material ensures excellent protection against corrosion, especially in environments exposed to saltwater or aggressive chemicals—common in West African industrial installations.
RTJ sight glass flange drawing
Applications of RTJ Sight Glass Flanges
- Oil & Gas Pipeline Monitoring
- Petrochemical Processing Plants
- Marine & Offshore Installations
- Chemical Manufacturing Facilities
- Power Generation Systems
Why Choose Haihao Group for Sight Glass Flanges?
- Over 30 years of expertise in manufacturing high-performance pipe fittings and flanges for global industries.
- Ability to customize dimensions, materials, and pressure ratings based on client requirements.
- Strict quality control including material certification, pressure testing, and dimensional inspection.
- International standard compliance: ASME, DIN, JIS, GB/T, ISO certified production.
- Reliable worldwide supply experience covering regions including Africa, the Middle East, Southeast Asia, and Europe.
Looking for high-quality RTJ sight glass flanges or other pipeline components tailored to your project needs? Haihao Group offers expert engineering support, custom fabrication, and global delivery.
