High-Pressure Corrosion Defense: Haihao Group Dispatches Inconel 625 Weld Neck Flanges to Singapore

Haihao Group has completed precision forging, CNC machining, and final quality dispatch for a specialized order of high-pressure nickel-alloy flanges supplied to an offshore energy infrastructure project in Singapore. Engineered to withstand high internal working pressures and harsh marine environments, this shipment features 2” Class 1500 Schedule 40S raised face (RF) weld neck flanges manufactured from Inconel 625 nickel-chromium alloy under ASTM B564 UNS N06625 specifications and ASME B16.5 standards.

Order Technical Breakdown

Partnering with an established ASTM B564 UNS N06625 flange supplier ensures precise neck bore matching, controlled raised face serrations, and complete heat traceability for offshore processing units. Below are the verified parameters for the Singapore consignment:

Flange Type: Weld Neck Flange (WN).

Nominal Pipe Size (NPS): 2 Inch (DN50).

Pressure Rating: Class 1500 (ASME B16.5).

Wall Thickness / Schedule: Schedule 40S (SCH-40S).

Sealing Facing: Raised Face (RF) with smooth serrated finish.

Material Specification: ASTM B564 UNS N06625 (Inconel 625 Nickel-Chromium Alloy).

Dimensional Standard: ASME B16.5 (Pipe Flanges and Flanged Fittings).

Engineering Integrity: Inconel 625 Metallurgy in High-Pressure Marine Lines

Small-diameter high-pressure piping in offshore platforms experiences cyclic mechanical fatigue, severe thermal shocks, and aggressive chloride attack. Standard stainless steel flanges risk pitting and stress corrosion cracking in such extreme operational environments.

As a dedicated ASTM B564 UNS N06625 flange supplier, Haihao Group uses premium nickel-based forgings to deliver exceptional structural integrity:

Pitting & Crevice Corrosion Immunity: Containing over 58% nickel, 20-23% chromium, and 8-10% molybdenum, Inconel 625 offers near-total immunity to chloride pitting, crevice corrosion, and marine stress cracking.

Solid Solution Strengthening: Additions of niobium (3.15–4.15%) act with molybdenum to stiffen the alloy matrix, yielding high tensile strength (minimum 120 ksi / 827 MPa) without requiring age-hardening heat treatments.

Class 1500 Heavy-Wall Design: The tapered weld neck hub gradually transfers stress from the flange ring to the 2” Schedule 40S pipe wall, preventing localized strain at high operating pressures (1500# Class rating).

Machining Precision, Surface Finish & Quality Control

To maintain our standing as a top-tier ASTM B564 UNS N06625 flange supplier, every item passed comprehensive quality gates prior to export:

Raised Face Serration: Sealing faces were CNC-turned to 125–250 μin.Ra( 3.2-6.3 μm Ra) smooth serrations, ensuring optimal seating stress for spiral wound gaskets in high-pressure lines.

Bore & Bevel Verification: Hub bores were precision-machined to match the exact internal diameter of Schedule 40S pipe, preventing internal flow erosion and step discontinuities.

Positive Material Identification (PMI): 100% handheld XRF testing verified elemental composition (Ni, Cr, Mo, Nb) across all forgings.

Complete Certification Package: Shipped with EN 10204 3.1 Mill Test Certificates detailing heat chemical analysis, mechanical yield/tensile values, and non-destructive examination (NDE) reports.

Selecting a certified ASTM B564 UNS N06625 flange supplier guarantees smooth field fit-up and long-term operational safety in demanding offshore hydrocarbon assets.

Partner with Haihao Group for Singapore Marine Projects

Looking for high-pressure nickel alloy flanges, Inconel 625 ASME B16.5 weld neck components, or custom forged fittings for your marine and chemical loops in Singapore? Rely on a trusted ASTM B564 UNS N06625 flange supplier. Contact the Haihao Group engineering sales team today for fast technical support and competitive pricing.
