Pipe and fitting ends in piping system joint

A pipe or fitting may have different type of ends on both ends,for example,one end is Plain end and the other is threaded end,or one end is socket weld and the other end is threaded,or one end is NPT thread and another is BSPT standard thread.

NPT-SCHXS-A234-WPB-ANSI-B16.11-Swage-Nipple

NPT-SCHXS-A234-WPB-ANSI-B16.11-Swage-Nipple

For easy understanding and recording, people use abbreviations for the pipe ends.Following are the Abbreviations for different kinds of pipe ends.In general, they are used to descripe the ends type of nipples, couplings, sockets, swages and other pipe fittings.

Bevel End (BE) End of Pipe (EOP) Thread Large End (TLE)
Bevel Both Ends (BBE) Flange One End (FOE) Thread One End (TOE)
Bevel Large End (BLE) Plain End (PE) Thread Small End (TSE)
Bevel One End (BOE) Plain Both Ends (PBE) Threads Only (TO)
Bevel Small End (BSE) Plain One End (POE) Threads per Inch (TPI)
Bevel for Welding (BFW) Thread End (TE) Butt welding (BW)
Buttweld End (BE) Thread Both Ends (TBE) Socket welding (SW)

Hebei Haihao Group piping solutions team can supply the steel pipes and fittings with various ends as per your design request.If you have any question contact us now.
